Technical parameters
Measuring function
Test parameters
Dc voltage, AC voltage, DC current, AC current, DC resistance, capacitance, frequency, conduction, diode, temperature
Mathematical function
% 、dB、dBm、REL、mX+b
The range of
Automatic, manual
The monitor
高亮度VFD双参数The monitor
Trigger mode
INT/BUS/EXIT
The reading holds
Find the best stable reading for the given number of data blocks within the set error range
The HI,Lo and IN (PASS) states can be distinguished
Limit measurement
And can be set in any state to emit a sound
(Can be turned on/off)
Calibrate
自动Calibrate、手动Calibrate
External trigger
Handle 接口（External trigger,输出分选信号）
Communication interface
USB ,RS232C,SCPI command programming support
The uncertainty of performance parameters is expressed as ± (percent of the reading on the full scale)
Reading rate (reading/second)
Reading rate
Fast
Slow speed
4 1/2
5 1/2
4 1/2
5 1/2
DCV/DCI
100
15
15
4
ACV/ACI
100
15
15
4
Ω
100
15
15
4
Direct current voltage (DCV)
The range of
Minimum resolution
Maximum uncertainty (1 year)
100mV-1000V
1µV
0.02%+0.005%
Direct current (DCI)
The range of
Minimum resolution
Maximum uncertainty (1 year)
1mA-100mA
10nA
0.05%+0.005%
1A
10µA
0.10%+0.008%
10A
100µA
0.20%+0.006%
Ac voltage (ACV)
The range of
Bandwidth
Minimum resolution
Maximum uncertainty (1 year)
100mV-750V
20Hz-50Hz
1µV
1.00%+0.1%
50Hz-10kHz
0.20%+0.08%
10kHz-30kHz
0.80%+0.08%
30kHz-100kHz
2.00%+0.2%
Alternating current (ACI)
The range of
Bandwidth
Minimum resolution
Maximum uncertainty (1 year)
1mA -10A
20Hz-50Hz
10nA
1.0%+0.08%
50Hz-2kHz
0.5%+0.08%
2kHz-10kHz
2.0%+0.18%
Resistance
The range of
Minimum resolution
Maximum uncertainty (1 year)
100Ω-1MΩ
10µΩ
0.05%+0.008%
10MΩ
100Ω
0.20%+0.008%
100MΩ
1kΩ
2.00%+0.005%
Capacitance
The range of
Minimum resolution
Maximum uncertainty (1 year)
1nF
1pF
2%+0.8%
10nF-1000uF
10pF
1.0%+0.5%
10000uF
1uF
2%+0.5%
Frequency
Test range
Voltage sensitivity
Minimum resolution
Maximum uncertainty (1 year)
1Hz-1MHz
40mV rms
10µHz
0.005%+0.003%
Temperature
Test range
Probe type
Minimum resolution
Maximum uncertainty (1 year)
-10 ℃ -100 ℃
PT500
0.1 ℃
Probe accuracy ±0.2 ℃
Temperature在范围之外的测量不保证准确度
Attachment
| Standard configuration | |||||
| Part name | Model number |
|
|
|
|
| Multimeter test cable | TH26036(JC-BBA03601) |
|
|
|
|
| Optional | |||||
| Part name | Model number |
|
|
|
|
| TH1951/61 four terminal test wire | TH26039 |
|
|
|
|
