Technical parameters
Product model
TH1963
TH1963A
TH1953
The monitor
4.3 "LCD color disy
Disy digit
1199999 word reading
119,999 word reading
Measurement parameters
Dc voltage, AC voltage, DC current, AC current, DC resistance, capacitance, frequency, conduction, diode, temperature
Disy mode
Direct reading, histogram, bar graph, trend graph
Measure the speed of
The highest 1000 times /s
Mathematical function
Zero clearing function, minimum value / Max/mean/standard deviation,dB,dBm
General function
The range of
Automatic, manual
Trigger mode
L O C A L ： A U T O / S I N G L E / EXTREMOTE：IMMEDIATE/BUS/EXT
The reading holds
There is
Limit measurement
HI,Lo, and IN (PASS), with ring
Technical index
Expression of uncertainty: ±(%读数+%The range of) ,TCAL=25℃
Parameter
The range of / Test range
Frequency
The highest年精度 TCAL ±5°C
The highestTemperature系数
/°C
TH1963
TH1963A
TH1953
Dc voltage
100.0000mV-1000.000V（TH1963/TH1963A）
100.000mV-1000 00V（TH1953）
0.0035+0.0005
0.0075+0.0005
0.010+0.004
0.0005+0.0001
真There is效值交 Current voltage
100.000mV-750.000V
3-5Hz
5-10Hz
10Hz-20kHz
20-50kHz
50-100kHz
100-300kHz
1.00+0.03
0.35+0.03
0.06+0.03
0.12+0.05
0.60+0.08
4.00+0.50
1.00+0.03
0.38+0.03
0.09+0.03
0.15+0.05
0.63+0.08
4.00+0.50
1.00+0 03
0.38+0.03
0.09+0.03
0.15+0.05
0.63+0.08
4.00+0 50
0.100+0.003
0.035+0.003
0.005+0.003
0.011+0.005
0.060+0.008
0.200+0.020
Dc resistance
10Ω- 100M Ω, test current: 10 Ma -500nA
0.010+0.001
0.014+0.001
0.030+0.004
0.0006+0.0001
Direct current
100 μA-10mA
100mA
1A
3A
10A
0.050+0.006
0.050+0.004
0.100+0.004
0.200+0.020
0.120+0.010
0.050+0.005
0.050+0.004
0.100+0.004
0.200+0.020
0.120+0.010
0.050+0.008
0.050+0.004
0.100+0.004
0.200+0.020
0.250+0.004
0.0020+0.0005
0.0020+0.0005
0.0050+0.0010
0.0050+0.0020
0.0050+0.0010
Ac current
100 μA– 100mA
3Hz-5kHz
5kHz-10kHz
0.10+0.04
0 10+0 04
0.10+0.04
0 10+0 04
0.10+0.04
0 10+0 04
0.100+0.006
0 030+0 006
1A
3Hz-5kHz
5kHz-10kHz
0.10+0.04
0.10+0.04
0.10+0.04
0.10+0.04
0.10+0.04
0.10+0 04
0.015+0.006
0.030+0.006
3A
3Hz-5kHz
5kHz-10kHz
0.23+0.04
0.23+0.04
0.23+0.04
0.23+0.04
0.23+0.04
0.23+0 04
0.100+0.006
0.030+0.006
10A
3Hz-5kHz
5kHz-10kHz
0.15+0.04
0 15+0 04
0.15+0.04
0 15+0 04
0.15+0.04
0 15+0 04
0.100+0.006
0 030+0 006
Frequency
3Hz-10Hz
10Hz-100Hz
100Hz-1kHz
100Hz-300kHz
Square wave
0.100
0.030
0.010
0.010
0 010
0.100
0.030
0.012
0.012
0 012
0.100
0.030
0.012
0.012
0 012
0.0002
0.0002
0.0002
0.0002
0 0002
Diode
5V, test current: 1mA
0.010+0.030
0. 1+0.02
0.0010+0.0020
Conduction
1kΩ, test current: 1mA
0.010+0.030
0. 1+0.02
0.0010+0.0020
Capacitance
1.0000nF
10.000nF-1.0000mF
10.000mF
1.0+0.5
0.5+0.1
1.0+0.5
0.02
0.02
0.02
Temperature
PT100(DIN/IEC751)
5kΩ thermistor
±0.05°C
±0.10°C
Attachment
| Standard configuration | |||||
| Part name | Model number |
|
|
|
|
| Optional | |||||
| Part name | Model number |
|
|
|
|
