Technical parameters
Model number
TH9201
TH9201S
TH9201B
Eight-way matrix scanner
------
There is
------
耐压测试
Output voltage
AC
0.05kV - 5.00kV ± 2% （ 50 、 60Hz (Optional)
DC
0.05kV - 6.00kV ± 2%
Current test range
AC
0.001mA - 30mA
0.001mA - 20mA
DC
0.1 μ A - 10mA
0.1 μ A - 5mA
Test accuracy
± （ 1% The reading +5 (a word)
Discharge function
Automatic discharge (--) after the test DCW ）
Insulation resistance test
Output voltage
0.05kV - 1.00kV ± 2%
Resistance test range
0.1M Ω - 50G Ω , ( The current ranges from 10nA-10mA)
电阻Test accuracy
0.1MΩ - 300MΩ Range ±5percent 2 words
300M Ω - 3G Ω Range ±10percent 2 words
3G Ω - 50G Ω Range ±20percent 2 words
Discharge function
测试结束后自动放电
Arc detection
Measuring range
AC
1mA - 15mA
DC
1mA - 10mA
1mA - 5mA
The general parameter
Voltage rise time
0.1s - 999s
Voltage drop time
0.1s - 999s
Voltage wait time
0.1s - 99.9s( Dc only)
Interface
RS232 , USB , HANDLER , REMOTE I/O , SCAN , GPIB( Optional item )
Attachment
| Standard configuration | |||||
| Part name | Model number |
|
|
|
|
| High pressure test stick | TH90004 |
|
|
|
|
| High voltage test cable (black) | TH90003B |
|
|
|
|
| High voltage test cable (red) | TH90003R |
|
|
|
|
| Optional | |||||
| Part name | Model number |
|
|
|
|
