Application field:
It is widely used in intelligent substation, conventional substation, electric power department, railway department, industrial and mining enterprises, field electrical work and detection stations
Product Features:
1, touch the color screen, Chinese interface, easy and quick operation;
2, single machine can be used as a three-phase voltammeter;
3. The dual machine can be used as a wireless phase voltammeter, which can test the current in different positions of the substation
Voltage, phase, power, frequency, power factor, etc.; With single-phase or three-phase test mode;
4. Users can use 3 or 4 handheld terminals for online testing according to their needs;
5, the measuring personnel only need to connect the operation, the instrument will automatically measure, real-time update data, easy to spot analysis;
6, the instrument adopts complete isolation technology to avoid the occurrence of safety accidents;
7, using LORA wireless communication, transmission distance, up to 1000m (in open ces)
量程与Precision（基准条件下）
Type of measurement |
Measuring range |
Precision |
Resolution |
Voltage |
2V～700V |
±0.3%rdg |
0.0001 |
Current |
0.001A-20A |
±0.3%rdg |
0.0001 |
Phase |
0°～360° |
±0.3° |
0.1 |
Frequency |
45Hz～65Hz |
±0.03Hz |
0.0001 |
Active power |
0.002W～14000W |
±0.3%rdg |
0.0001 |
Reactive power |
0.002VAR～14000VAR |
±0.3%rdg |
0.0001 |
Apparent power |
0.002VA～14000VA |
±0.3%rdg |
0.0001 |
Other technical specifications
Basic function |
|
Function option |
Touch screen selection |
Means of communication |
Wireless LORA（230MHz） |
Wireless通讯距离 |
1km (in open space) |
Measure The test line |
黄、绿、红、BlackVoltageMeasure试线,各 2根 |
Electricity Flow pliers |
Mouth size φ8mm,6 |
Data storage |
200 groups |
Data upload |
USB接口,Measure试记录Data upload计算机,可导出为Excel格式 |
Electricity池Voltage |
Electricity池Electricity量指示显示,Electricity池Voltage低于 10%时提醒及时充Electricity |
Automatic shutdown |
After the boot 15分钟无操作Automatic shutdown,关机前提醒关机 |
Working hours |
充满Electricity时,持续Working hours 12 hours |
Work Consumption |
Work (backlight for 50）：320mA; |
Working conditions |
Temperature: -20 ~ 50℃, relative humidity: 0 ~ 95percentHR No condensation |
Basic parameter |
|
Electricity源 |
DC 7.4V 5200mAH可充Electricity锂Electricity池 |
Disy size |
108mm×65mm (5 "touch color screen) |
Fuselage color |
Black Orange |
Fuselage weight |
About 870g |
Fuselage size |
210mm×129mm×68mm |
Standard parts |
Current钳： 6件;Measure试线：8条;充Electricity器：2个;USB通讯线：2条;仪表箱：1件 |
Standard inner packing |
Neutral carton |
Size of outer packing |
49x36x18cm |
Standard packing quantity |
1 |
Gross weight of standard packing case |
About 4KG |
