Technical parameters
Model number
TH9410A
TH9411A
Output
Current
The scope of
1A-45A
1A-32A
The range of
1.00A-5.00A
5.01A-30A
30.01A- 45A
1.00A-5.00A
5.01A-32A
Precision
±(2percent reading 3 words)
Set the resolution
0.01A
Read back resolution
0.01A
OutputVoltage
8Vmax
6Vmax
8Vmax
Frequency
50 / 60Hz：± 0.1%SET
Resistance
测试The scope of
0-600mΩ（Rmax ≤ 6 / Iset（Iset：当前SetCurrent））,当Current≤10A时Resistance可设600mΩ
Precision
± (2percent) reading 2 words
Resolution
1 mΩ
0.1 mΩ
0.1 mΩ
1 mΩ
0.1 mΩ
Set
Upper limit
0-600mΩ
Lower limit
0-600mΩ（必须小于Upper limit）
Resolution
1mΩ
Offset
The scope of
0 - 100 mΩ
Resolution
0.1mΩ
Precision
± (2percent set 2 words)
Test time
The scope of
0, 0.5-999.9s (0 = continuous)
Resolution
0.1s
Precision
± (0.1% + 0.05s)
Input power
Voltage
110V,220V
Frequency
47.5-63Hz
Power consumption
≤900VA
≤ 800VA
Volume
340mm×120mm×450mm
340mm×120mm×450mm
The weight of
About 15kg
About 15kg
Attachment
| Standard configuration | |||||
| Part name | Model number |
|
|
|
|
| Optional | |||||
| Part name | Model number |
|
|
|
|
