Technical parameters
Measuring technical indicators
The scope of
Resolution
Precision
Dc voltage
0-12.000(kV)
0.001
±1%
Ac voltage
0-10.000(kV)
0.001
±1%
Conventional technical indicators
The monitor
Large 4 Bit half 7 Segment LED The monitor
Input impedance
100M Ω ±1%
Dimensions and specifications
280 ( W ) x133(H)x400(D) mm/3.3Kg
Input voltage
220V±15%
Frequency
50/60HZ±5%
The fuse
F2A/250V
Attachment
| Standard configuration | |||||
| Part name | Model number |
|
|
|
|
| Optional | |||||
| Part name | Model number |
|
|
|
|
