Application field:
Be applicable to LED drive power production field testing, quality control or R & D testing and other occasions
Product Features:
Can be tested simultaneously The input and output electrical properties of LED driving power;
THD harmonic analysis function;
Real-time disy of voltage and current waveform;
Automatic alarm function over limit.
Technical specifications
Basic function |
VICTOR 7900 |
||
Input characteristic test |
|||
Test function |
Measure input voltage true RMS, current true RMS, active power, power factor, frequency and voltage, current total harmonic distortion, 0-50 times True RMS and relative values of harmonics, efficiency test, electric energy integral |
||
Input characteristic measurement range |
Voltage |
5V-600V |
|
Current |
5mA-20A |
||
Frequency |
DC,45Hz-65Hz |
||
Measurement accuracy |
± (0.15% reading + 0.15% range) |
||
Output characteristic test |
|||
Output steady-state characteristic test |
测量输出稳态时的Voltage真有效值、Current真有效值、有功功率、功率因数、电能积分 |
||
Output characteristics measurement range |
Voltage |
3V-300V |
|
Current |
5mA-10A |
||
Frequency |
DC,45Hz-65Hz |
||
Measurement accuracy |
± (0.15% reading + 0.15% range) |
||
Special function |
|
||
Latch function |
√ |
||
Chinese and English interface |
√ |
||
Alarm function |
Voltage、Current、功率报警 |
||
Basic parameter |
|
Power supply |
AC 100V～240V 45～60Hz |
Disy size |
800x480 lattice color LCD disy |
Fuselage color |
Off-white |
Fuselage weight |
About 3.5KG |
Fuselage size |
215mmx132mmx275mm |
Standard parts |
|
Standard inner packing |
The carton |
Size of outer packing |
38.3*29*23cm |
Standard packing quantity |
1 |
Gross weight of standard packing case |
About 4.2 KG |
