Product Description:

JK-8U multichannel temperature tester equipped with large screen LCD screen,U disk save interface, can be convenient to measure disy and save temperature data, is a kind of multi-point real-time monitoring and tracking instrument

The use of high voltage semiconductor relay as a switching input signal scanning, to achieve high speed scanning, eliminate the noise and service life of the traditional relay

Technical characteristics:

The upper and lower limit temperature of each channel can be set. Large screen liquid crystal disy, can disy multiple temperature values at the same time with U disk interface, insert U disk can store mass temperature record data

Especially for oven, sterilization cabinet, lamps, household appliances, motors, electric heating appliances, temperature controllers, transformers, heat protectors and other industries of manufacturers and quality inspection departments of the multi-point temperature field detection

Energy saving lamp, electronic ballast internal transistor, choke, magnetic ring, capacitor and other components of the temperature at the same time live monitoring, by the computer will be the whole temperature change process all in curve way

Record, easy to analyze, improve, to improve the reliability of energy-saving lamps, electronic ballast ys a great role

Instrument features:
1, multi-channel temperature test software and instrument use, the computer automatically receive test data, temperature record, storage and curve disy, and print forms and curves

2、JK-XU可以设定参数选用1~64路任意路测量,配接不同的热电偶满足不同的温度Measuring range;大屏幕液晶Show,各路温度参数和温度曲线Show,

(all the temperature values of the disy and one temperature alarm channel) computer serial communication directly connected to the computer data collection, the software is specifically for the user's special requirements of multi-channel temperature at the same time, can either

Test a sample or more different samples at the same time, or record the name of multiple test sites, can also test a sample or more different samples at different inches, can set the temperature Curve color, have professional design simple

The traditional Chinese and English versions are suitable for a variety of different test purposes

3, cold end ambient temperature: measuring range of 0 ~ 60℃

4, the machine also has the date and time setting with fixed point, inspection function; Inspection time can be set: 1 second to 255 seconds, measurement interval can be set (no less than 1 second);

5, the temperature unit Celsius (C) Fahrenheit (F) can be automatically converted; An instrument can choose T, J and K thermocouple

6, the test channel can be arbitrarily set to meet the requirements and speed of measurement;

7. The status bar disys the setting parameters in real time; Uneven degree of each channel: 0.5℃

8, thermocouple probe can contact no more than 300V DC charged objects for measurement without damaging the instrument; The thermocouple probe can contact the heating body has the relevant limit, the temperature range must be put forward when ordering, in order to provide the corresponding protective materials

JK-XU/XA multichannel temperature tester is suitable for lamp, household appliance, motor, electric heating appliance, temperature controller, transformer, heat protector and other industries of manufacturers and quality inspection departments to detect multi-point temperature on the spot

Note:

① T, J and K in the table are the models of the probes, and the temperature ranges are :

J-mark -100 ~ 750

K marks range from 100 to 1200

T index is -100 to 400

Curve: refers to the instrument does not software in the LCD screen real-time disy temperature curve and stored in the instrument, can be permanently saved in the computer through the communication interface curve

③ Data: refers to the instrument does not software temperature value to serial number, number, collection time and the corresponding temperature value stored in the instrument, can be permanently stored in the computer through the communication interface data

Instrument factory each road is equipped with 2 meters long temperature measurement (temperature resistance 250℃) wire, if need to be extended by 10 yuan/meter calculation! With K line in order to prevent the impact of sudden power failure test, it is recommended to match UPS power supply

The difference between 3 multichannel temperature tester:

Model number	JK-8U	JK-8A	JK-8C
Input type	Sensor: Nichcr - Nichsi (K type) thermocouple (T type,J type can be specially made)
Measuring range	1, temperature range: -100℃ ~ 1000℃; 2, the accuracy of measurement: 0 ~ 1000 ℃, plus or minus (reading value x 0.5 percent 1) ℃, - 100 ~ 0 ℃ : plus or minus numerical x 0.5 percent (reading 2) ℃;
Number of channels 8	8路 16路 24路 Route 32 40路 48路64路
Show	LCD 240*128 lattice screen
单屏多Show	Route 32
U disk storage	There is	None	There is
Live test	< 300V DC
Internal storage	There is	None		There is
Alarm mode	The numbers flicker
Dry winding resistance	Resist high frequency interference
Communication interface	USB	RS232
Supporting software	2014 edition (latest)	2000 edition
Allow environmental conditions	1, power supply: AC 220V±10percent,50Hz±2percent; 2, the use of environment: working temperature: -20-70℃, relative humidity: 20%-90percent; 3、热电偶相互之间电位差：＜350V（真There is效值）
Overall dimensions	(W * H * D)248*128*305mm Machine weight: about 5kg

---
