Technical parameters
Model number
TH8401
TH8402
TH8402A
TH8403
TH8404
TH8405
TH8411
TH8412
Rated parameter
Power
175W
350W
350W
1000W
1500W
2000W
175W
350W
Voltage
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~50V
0~500V
0~50V
0~500V
Current
0~3A
0~30A
0~3A
0~30A
0~6A
0~60A
0~3A
0~120A
“ 0~3A
0~180A
0~6A
0~240A
0~1.5A
0~15A
0~3A
0~30A
小操作Voltage
1.5V@30A
1.2V@30A
1.5V@60A
1.5V@120A
1.2V@180A
1.5V@240A
1.8V@15A
3V@30A
小上升时间
20uS
CV Mode
The scope of
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~50V
0~500V
0~50V
0~500V
Resolution
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
Precision
0.05%+0.05%FS
CC Mode
The scope of
0~3A
0~30A
0~3A
0~30A
0~6A
0~60A
0~3A
0~120A
0~3A
0~180A
0~6A
0~240A
0~1.5A
0~15A
0~3A
0~30A
Resolution
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1 mA
0.1mA
1mA
0.1mA
1mA
Precision
0.05%+0.05%FS
CR Mode
The scope of
0.05 Ω ~20k Ω
0.05 Ω ~20k Ω
0.03 Ω ~15k Ω
0.02 Ω ~30k Ω
0.02 Ω ~20k Ω
0.01 Ω ~15k Ω
0.02 Ω ~50k Ω
0.1 Ω ~50k Ω
Resolution
0.05 Ω
0.05 Ω
0.1 Ω
Precision
1%
1%
CP Mode
The scope of
0~175W
0~350W
0~350W
0~175W
0~350w
0~350w
0~175W
0~350w
Resolution
10mW
10mW
10mW
10mW
10mW
10mW
10mW
10mW
Precision
0.5%+0.1%FS
动态Mode
The scope of
20 us ~ 60S
Resolution
2 us
Precision
2uS+100ppm
The rate of increase
0.6A/ms~1.5A/ µS
0.6A/ms~1.5A/ µS
1.2A/ms~3A/µS
2.4A/ms~6A/µS
3.6A/ms~9A/µS
4.8A/ms~12A/µS
0.3A/ms~0.75A/ µs
0.6A/ms~1.5A/µs
Voltage测量
The scope of
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~50V
0~500V
0~50V
0~500V
Resolution
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
1mV
10mV
Precision
0.08%+0.05%FS
Current测量
The scope of
0~3A
0~30A
0~3A
0~30A
0~3A
0~30A
0~3A
0~120A
0~3A
0~180A
0~6A
0~240A
0~1.5A
0~15A
0~3A
0~30A
Resolution
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
0.1mA
1mA
Precision
0.08%+0.05%FS
Ripple measurement
The scope of
0~15V
0~150V
0~15V
150V
0~15V
150V
0~15V
0~150V
0~15V
0~150V
0~15V
0~150V
0~50V
0~500V
0~50V
0~500V
Bandwidth
250kHZ
Precision
0.1%
Protection function
Overvoltage protection (OVP) Overcurrent protection (OCP) 过Power保护 (OPP)
Store
Inside 20 Group
Specifications
Volume (mm)
(W*H*D)
215×88×390
Shelf volume: 215×88×390
Volume: 236×111×454
430mm*88mm*529mm
Shelf volume: 215×88×390
Volume: 236×111×454
The weight of
3kg
4.8kg
3kg 13kg 15.5kg 18kg 3kg
4.8kg Power supply
Power supplyVoltage : 220V(1 ± 10%) ,Power supply频率 : 50Hz/60Hz(1 ± 5%) Power consumption : <50VA
Temperature and humidity
0 ℃ ～ 40 ℃ Humidity : <90%RH
