Technical parameters
Measurement mode |
Ultrasonic wave |
ne measuring range |
3m~23m |
Resolution |
5mm(＜10m) 10mm(＞10m) |
Minimum distance between cables |
150mm |
Measurement accuracy |
0.5%±2dgt |
Automatic shutdown function |
There is |
LCD backlight disy function |
There is |
Ambient temperature measurement |
There is |
Low power prompt function |
There is |
BOT mode |
Measure the distance of the lowest 6 cables in turn |
TOP mode |
Measure the distance of the highest 6 cables in turn |
Packing specifications
Power supply |
9V battery |
Net weight of product |
240g |
Product size |
75*72*200mm |
The way of packing |
Color box packing |
Standard outer box capacity |
12 |
Standard outer box size |
52.5*33.5*47cm |
Standard gross weight of outer box |
11.46kg |
