Rated output (0 ℃ -40 ℃ )

Channel / The scope of

The scope of 1

The scope of 2

The scope of 1

The scope of 2

The scope of 1

The scope of 2

The scope of 1

The scope of 2

The scope of 1

The scope of 2

Voltage

0-20V

0-8V

0-32V

0-15V

0-72V

0-32V

0-32V

0-15V

0-72V

0-32V

Current

0-5A

0-10A

0-3A

0-6A

0-1.5A

0-3A

0-6A

0-12A

0-3A

0-6A

Power

100W

80W

96W

90W

108W

96W

192W

180W

216W

192W

Load adjustment rate ± (% Output + offset )

Voltage

≤ 0.01% + 4mV

≤ 0.01% + 3mV

≤ 0.01% + 3mV

≤ 0.01% + 6mV

≤ 0.01% + 5mV

Current

≤ 0.01% + 2mA

≤ 0.01% + 5mA

≤ 0.01% + 4mA

Power adjustment rate ± (% Output + offset )

Voltage

≤ 0.01% + 4mV

≤ 0.01% + 3mV

≤ 0.01% + 3mV

≤ 0.01% + 6mV

≤ 0.01% + 5mV

Current

≤ 0.01% + 2mA

≤ 0.01% + 5mA

≤ 0.01% + 4mA

Programming resolution

Voltage

1mV

Current

0.1mA

Read back resolution

Voltage

1mV

Current

0.1mA

Annual accuracy (25 ℃± 5 ℃）± (% Reading + offset )

Programming

Voltage

≤ 0.04% + 8mV

Current

≤ 0.1% + 5mA

Read back

Voltage

≤ 0.04% + 8mV

Current

≤ 0.1% + 5mA

Ripple and noise (20Hz-20MHz)

差模Voltage

≤ 3mVp-p/1mVrms

≤ 3.5mVp-p/1mVrms

≤ 3mVp-p/1mVrms

≤ 4mVp-p/1mVrms

差模Current

＜ 9mArms

＜ 7mArms

＜ 6mArms

≤ 0mArms

≤ 8mArms

共模Current

<1.5 μ Arms

Transient response

＜ 50uS ( 在输出Current从满度变化到半满度,或从半满度变化到满度时,输出恢复到 75mV The time within )

＜ 50uS ( 在输出Current从满度变化到半满度,或从半满度变化到满度时,输出恢复到 120mV The time within )

＜ 50uS ( 在输出Current从满度变化到半满度,或从半满度变化到满度时,输出恢复到 75mV The time within )

Rise time (10% — 90%)

＜ 90ms

＜ 120ms

＜ 180ms

Decline time (90% — 10%)

＜ 150ms

＜ 200ms

＜ 250ms

＜ 350ms

＜ 250ms

Precision of series-parallel setting

Voltage

------

Current

------

A timer

0.1 ～ 99999.9 Second

Storage

10 Group triggers output , Each group of 100 A step; 100 Group set memory
