Rated output (0 ℃ -40 ℃ )

passageway / Range

CH1

CH2

CH3

CH1

CH2

CH3

CH4

CH1

CH2

CH3

CH1

CH2

CH3

CH1

CH2

CH3

Voltage

0-30V

0-5V

0-30V

0-10V

0-5V

0-30V

0-6V

0-30V

0-6V

0-60V

0-6V

electric current

0-3A

0-3A

0-1A

0-3A

0-5A

0-6A

0-5A

0-3A

0-5A

power

90W

15W

90W

30W

5W

90W

30W

180W

30W

180W

30W

Load adjustment rate

Voltage

≤ 0.01%+3mV

electric current

≤ 0.1%+3mA

≤ 0.01%+3mA

Power adjustment rate

Voltage

≤ 0.01%+3mV

electric current

≤ 0.1%+3mA

≤ 0.01%+3mA

Set value resolution

Voltage

10mV

1mV

electric current

1mA

0.1mA

Read back resolution

Voltage

10mV

1mV

electric current

1mA

0.1mA

Setting value accuracy

(25 ℃± 5 ℃ )

Voltage

≤ 0.05%+20mV

≤ 0.1%+20mV

≤ 0.03%+10mV

electric current

≤ 0.2%+5mA

≤ 0.2%+5mA

≤ 0.1%+5mA

≤ 0.1%+8mA

≤ 0.1%+5mA

≤ 0.1%+5mA

Readback value accuracy

(25 ℃± 5 ℃ )

Voltage

≤ 0.05%+20mV

≤ 0.1%+20mV

≤ 0.03%+10mV

electric current

≤ 0.2%+5mA

≤ 0.2%+5mA

≤ 0.1%+5mA

≤ 0.1%+8mA

≤ 0.1%+5mA

≤ 0.1%+5mA

Ripples and noise (20Hz-20MHz)

Voltage (Vp-p)

≤ 3mVp-p

≤ 3mVp-p

≤ 3mVp-p

≤ 4mVp-p

≤ 4mVp-p

≤ 4mVp-p

Voltage（ rms ）

≤ 1mVrms

≤ 1mVrms

≤ 1mVrms

≤ 1mVrms

≤ 1mVrms

electric current

≤ 3mArms

≤ 3mArms

≤ 3mArms

≤ 5mArms

≤ 5mArms

≤ 4mArms

≤ 5mArms

Series synchronization error

≤ 0.02%+5mA

≤ 0.2%+10mA

≤ 0.05%+10mA

Parallel setting accuracy

Voltage

≤ 0.02%+5mV

≤ 0.02%+10mV

≤ 0.02%+5mV

≤ 0.02%+5mV

≤ 0.02%   +   10mV

electric current

≤ 0.1%+20mA

≤ 0.2%+20mA

≤ 0.1%+20mA

≤ 0.1%+30mA

≤ 0.1%+30mA

memory

Callback storage

40 Group settings file / passageway

timer

function

Timing off output

time setting

0.1 second～ 99999.9 second

Resolution

0.1 second

working temperature

0 ℃～ 40 ℃
