Settable voltage

0~33V

Rated output current

0~6A

Current can be set

0~6.3A

Output power;

192W

Load regulation rate

Voltage:<0.1%+5mV

Current:<0.2%+3mA

Power regulation rate

Voltage:<0.01%+5mV

Current:<0.2%+3mA

Set Resolution

Voltage: 10mV

Current: 1mA

Read back resolution

Voltage: 10mV

Current: 1mA

Set accuracy
(23°C±5°C)

Voltage:<0.1%+1 digit

Current:<0.2%+3mA

Readback accuracy
(23°C±5°C)

Voltage:<0.1%+1 digit

Current:<0.2%+3 digits

Ripple and noise
(20Hz~20MHz)

Voltage: ≤ 8mVrms

Current: ≤ 5mArms

temperature coefficient

Voltage: ≤ 300ppm/° C

Current: ≤ 300ppm/° C

Disy Type

LED Nixie tube disy

Working conditions

Temperature 0 ° C~40 ° C Relative humidity<80%

Storage conditions

Temperature -15 ° C~70 ° C Relative humidity<80%

Heat dissipation method

Air-cooled

supply voltage

AC 220V±10%

frequency

50Hz

Dimensions (W x H x D)

80mm (W) x 135mm (H) x 239mm (L)

weight

1.9kg

ambient temperature

25°C±5°C
