TH6501 High precision programmable linear DC power supply

Model:TH6501

Brand:同惠电子1

Introduction:The TH6500 series of high precision programmable DC power supply covers 6 models (96W-216W), its most outstanding advantages are ultra-high accuracy and resolution and extremely fast voltage rise rate. A voltmeter and ohmmeter are built into the instrument to allow users to test external voltage and resistance. TH6500 series power supply is linear, programmed output design, so the series of power supply has small ripple, low noise, high precision, strong stability of the excellent performance. The whole series uses 4.3 "TFT LED disy, all Settings and output parameters are disyed on the same screen, more intuitive to use. UI design instrument using menu operation, soft keys, knob control and input parameters, easy to use, can be well adapted to the production line fast operation and the application needs of universities and laboratories. The TH6500 series also has strong editable capabilities. The instrument can save 10 test files, each test file can be edited 100 test steps, when needed can be a key call, and support the test file cycle output. TH6500 series is equipped with RS232, USB HOST and USB DEVICE interfaces as standard. GPIB interface is optional. SCPI and MODBUS communication protocols are supported. The compact size, standard chassis size, and output front and rear panels make the TH6500 series power supply easily integrated into a standard cabinet.
