To achieve a variety of step-down converter experiments, from open loop, single loop control, double loop control, photovoltaic system MPPT(maximum power point tracking) and other experiments

The test point on the hardware circuit provides the real wave line presentation, which can be mutually verified with the principle and simulation

Provides power electronics analysis, design, simulation and implementation verification

Can be connected with PC terminal, real-time observation DSP internal waveform, and real-time control of internal parameters

Can make the basic students of DSP code writing can easily complete the program writing, quickly enter the digital control jaw domain

Provide complete experimental teaching materials, teaching AIDS each circuit diagram file,DSP hardware nning method, setting and program burning method, detailed experimental circuit principle and design
