The number disys 120,000 digits
VFD color dual disy screen
Automatic/manual shift
2-wire / 4-wire resistance measurement
True RMS (True RMS -- AC, AC DC)
Optional measurement speed
Temperature measurement
Frequency measurement
Max/min, REL, dBm/dB, comparison, mathematical operations, storage, call
| Specifications | |
| Maximum disy (full scale) | |
|
|
120,000 digits |
| Sample rate | |
| Slow speed | 5 1/2 disy, 10 times/second |
| Medium speed | 4 1/2 disy, 30 times/second |
| Fast | 3 1/2 disy, 60 times/second |
| Direct current voltage (DCV) | |
| Gear position | 100mV, 1V, 10V, 100V, 1000V 5个 |
| Accuracy | ±(0.012percent read value 5 bits) |
| Input impedance | 10MΩ |
| Ac voltage (ACV -- True RMS) | |
| Gear position | 100mV、1V、10V、100V、750V |
| Accuracy | 20Hz to 45Hz: ±(1percent read value 100 bits); 45Hz ~ 10kHz: ±(0.2percent read value 100 bits); 10kHz ~ 30kHz :±(1percent read value 100 bits); 30 KHZ to 100kHz: ±(3percent read value 200 bits) |
| Input impedance | 1.1MΩ is connected in parallel with about 100pF |
| Direct current (DCI) | |
| Gear position | 10mA, 100mA, 1, A, 10A, 4, i, i, i, i |
| Accuracy | 10mA, 100mA: ±(0.05percent read value 15 bits); 1A, 10A: ±(0.2percent read value 5 bits) |
| Ac current (ACI -- True RMS) | |
| Gear position | 10mA, 100mA, 1A, 10a4 |
| Accuracy | 10mA, 100mA file :20Hz ~ 50Hz: ±(1.5percent read value 100 bits); 50Hz ~ 10kHz: ±(0.5percent read value 100 bits); 10kHz~20kHz: ±(2percent read value 200 bits); 1A, 10A :50Hz~5kHz: ±(0.2percent read value 100 digits) |
| Resistance | |
| Gear position | 100Ω， 1kΩ， 10kΩ， 100kΩ， 1MΩ， 10MΩ， 100MΩ |
| 2线制 Accuracy | 100Ω file: ±(0.1percent read value 8 bits)(*); 1kΩ ~ 1MΩ 4: ±(0.08percent read value 5 bits); 10MΩ file: ± (0.3percent read value 5 bits); 100MΩ file: ±(3percent read value 8 bits) |
| 4线制 Accuracy | 100Ω : ±(0.05percent read value 8 bits)(*); 1kΩ~ 1MΩ 4: ±(0.05percent read value 5 bits); 10MΩ : ±(0.3percent read value 5 bits); 100MΩ : ±(3percent read value 8 bits) |
| Diode test | |
|
|
Open circuit voltage 2.0V; Test current 0.5mA |
| Frequency | |
|
|
10Hz~800kHz |
| Short circuit buzzer | |
|
|
1 ~ 1000Ω |
| Temperature | |
|
|
0°c ~ 300°c j, k, t |
| Other functions | |
|
|
Automatic/manual shift, 算术功能 : MX + B/ % / 1/X;值, 小值, dBm, dB, REL, Hold, 比较, Store, Recall |
| Disy screen | |
|
|
VFD color dual disy screen |
| Interface | |
|
|
I/O, USB设备，RS-232C—— |
| Power supply | |
|
|
AC 100V-240V ±10%, 50/60Hz |
| 尺寸& 重量 | |
|
|
265(W) x 107(H) x 350(L) mm; About 2.6 kg |
| Note: (*) in ""; REL" In mode | |
