Features:

Each device continuously drains the water in the box to the outside of the box

Specifications:

Dehumidification: through solid polymer electrolyte membrane electrolytic discharge of moisture
Humidity: about 20percentRH (no load in the box, according to the use of the environment)
材质:主体/ PMMA(丙烯树脂),框架/铝框,搁板/强化塑料(ID-S2P・W4P)・不锈钢(ID-S2S・w4)—
Shelf installation spacing: 50mm
Minimum shelf interval: reinforced stic shelf / 35mm, stainless steel shelf / 40mm
Shelf load resistance: reinforced stic shelf/about 10kg/ sheet, stainless steel shelf/about 20kg/ sheet
Shelf size: 490×460mm
Power supply: AC220V (including 100V special transformer) 50/60Hz (ID-S2 needs 2 power supplies,ID-W4 needs 4

【 Specification Sheet 】

Picture	The number is	Model number	Overall dimension (mm)	Internal dimension (mm)	Shelf te quality	Sales Packing	RMB(including tax)	Beijing inventory	Shanghai inventory	Japanese inventories	Refer to the delivery date	Query NO.	Optional quantity
	H1-4693-11	ID-S2P	574×517×1765	Room 560×483×736×2	Reinforced stic rack	One	24,200.00	0	0	0	About 20 days	**13	-
	H1-4693-21	ID-S2S	574×517×1765	Room 560×483×736×2	Stainless steel frame	One	24,300.00	0	0	0	About 20 days	**13	-
	H1-4693-12	ID-W4P	1152×517×1765	Room 560×483×736×4	Reinforced stic rack	One	42,800.00	0	0	0	About 20 days	**13	-
	H1-4693-22	ID-W4S	1152×517×1765	Room 560×483×736×4	Stainless steel frame	One	44,000.00	0	0	0	About 20 days	**13	-
	1-987-11	Spare shelf	-	490×460	Reinforced stic rack	1	260.00	0	0	171		**13	-
	1-045-11	Spare shelf	-	490×460	Stainless steel frame	1	440.00	0	0	555		**13	-

※ It will take about 18 days to send from Japan if Japan is in storage

※ The dehumidifier cannot control humidity. Please consult separately for humidity control function.※ External dimension does not include protrusion Freight charge is extra

※ Catalog Publishing page: Azovan Experimental Instruments and consumables Catalog 2019 No. 211

※ Catalogue Publication page: Azovon Experimental Instruments and consumables Catalogue 2017 No. 498
