Online power quality analyzer: LINAX PQ series

Avoid power quality problem | comprehensive power quality and energy consumption monitoring LINAX PQ3000, LINAX PQ5000

Panel mounting equipment for power quality monitoring in power systems.

Traditionally, power quality measurement is analyzed only as a response to equipment failures, process interruptions, or communication failures. However, all of these problems cost money, and no user wants to go through the same thing again just to be able to create a corresponding analysis record. Therefore, the greatest advantage of continuous power quality monitoring is that users can proactively set up their own testing system and the ability to find problems.

The LINAX PQ3000 can help detect these problems and provide data before the device causes any damage

To determine the root cause of the event when it occurs. The PQ3000 is Grade A equipment in compliance with the power quality standard IEC 61000-4-30 Ed.3. Therefore, the equipment can provide reliable and compatible information for regulatory agencies, negotiations with energy suppliers or internal quality control. Equipment also supports compliance reporting to voltage quality standard EN 50160.

产品亮点：

清晰

■ High resolution, color TFT disys are used to disy measurement data in high definition
■ Always visible status information (alarms, password protection, data records, time/date, etc.)
■ Clear design

■ Power quality monitoring complies with IEC 61000-4-30 Ed. 3
■ Energy consumption acquisition: meters and load curves
■ 设备状态监测

多功能

■ Language-specific in text menu navigation
■ Local arrangement of measurement information for fast data access
■ Service area for maintenance and commissioning

直观

灵活

■ Applicable to all network configurations with no hardware differences
■ Optional measurement variable values and measurement values
■ Freely defined alarm conditions with collective alarm and recording

■ Composable device design (functionality, interface,I/Os, auxiliary power)
■ 可直接集成到SMARTCOLLECT软件

Avoid power quality problems -- through continuous monitoring

Disruptions in energy supplies can lead to disruptions in production or equipment. People usually react when the economic damage is huge. However, many of these incidents could have been avoided if these signs had been confirmed in ongoing monitoring.

Any form of power quality monitoring provides a statistical assessment that allows comparisons with standards (e.g.,EN50160) or supply contracts, as well as records of events in the grid (e.g., power supply voltage drop).
