Features:
Forced pair flow mode
3
————————
実測値と設定値の確認が容易なPV・SV二段表示に加え,過昇温防止設定温度表示を採用しています。—
8ステップ4パターンのプログラム機能を標準装備し,試料の量・サイズに合わせて4タイプから選択できます。—
Specifications:
Temperature control: Room temperature 20 ~ 270℃
Temperature control mode: PID control,SSR output
付加機能:プログラム仕様→8ステップ×4パターンのプログラム機能—
安全装置:デジタル設定式過昇防止機能・過電流ブレーカー・バーンアウト機構(センサー断線時ヒーター)—
温度センサー:K熱電対×2個(温調用・過昇防止用×各1本)—
外装/内装:スチール粉体塗装/ SUS304(一部SUS443J1)—
AC100V50/60Hz 2.4m(3P)——
※
Power supply Note :
The commodity power supply is AC100V, please be sure to use with 100V transformer.
Related transformer products, please refer to Chinese 2019 No. 477 page /2017 No. 884 page or directly consult our company.
【 Specification sheet 】
| Picture | Number | Model | Inside dimensions (mm) | The door | Maximum temperature arrival time | Temperature distribution (JTMK05) | Temperature variation (JIS) | Sales
Packaging |
RMB(tax included) | Beijing inventory | Shanghai inventory | Japanese inventory | Refer to delivery date | Query NO. | Purchase quantity |
|
1-2126-31 | OFWP-300V | 300×327×300 | Left | About 20 minutes | ±3°C(at270°C) | ±1°C(at270°C) | 1 set | 14,700.00 12,495.00 | 0 | 0 | 15 |
|
**12 | - |
|
|
1-2126-32 | OFWP-450V | 450×447×450 | Left | About 45 minutes | ±8°C(at270°C) | ±1°C(at270°C) | 1 set | 16,800.00 14,280.00 | 0 | 0 | 9 |
|
**12 | - |
|
|
1-2126-33 | OFWP-600V | 600×497×500 | Left | About 55 minutes | ±8°C(at270°C) | ±1.5°C(at270°C) | 1 set | 19,400.00 16,490.00 | 0 | 0 | 11 |
|
**12 | - |
|
|
1-2126-34 | OFWP-300V-R | 300×327×300 | Right | About 20 minutes | ±3°C(at270°C) | ±1°C(at270°C) | 1 set | 14,700.00 12,495.00 | 0 | 0 | 2 |
|
**12 | - |
|
|
1-2126-35 | OFWP-450V-R | 450×447×450 | Right | About 45 minutes | ±8°C(at270°C) | ±1°C(at270°C) | 1 set | 16,800.00 14,280.00 | 0 | 0 | 4 |
|
**12 | - |
|
|
1-2126-36 | OFWP-600V-R | 600×497×500 | Right | About 55 minutes | ±8°C(at270°C) | ±1.5°C(at270°C) | 1 set | 19,400.00 16,490.00 | 0 | 0 | 3 |
|
**12 | - |
※日本在库的情况下,从日本寄送大概需要18天Left右
