Features:
Through hyperfine contrast processing, the outline of the object is clearer and easier to master the object
Built-in digital camera can save infrared images, digital camera images and ultra-fine contrast images at the same time
Using the no-focus function, the camera can be aimed at an object more than 50cm away, without focusing
With picture-in-picture function, you can put infrared images into digital camera images.
Specifications:
Accuracy :±2°C or ±2percent(ambient temperature 25°C)
Viewing Angle :45°
Detection element: uncooled microbolometer
Minimum focal length :0.5m
Memory: Built-in memory (can save more than 500 images)
Box function with maximum/minimum temperature disy
Color alarm clock function (blue/set temperature below, red/set temperature above)
Save form :JPEG
Power supply: lithium-ion battery
Size :244×95×140mm
Weight :575g(including battery)
Accessories: Battery,USB cable, charging cable, portable bag
【 Specification sheet 】
| Picture | Number | Model | Resolution | Decomposition energy (℃) | Temperature measurement Fan | Instantaneous field of view | インターフェース | Sales
Packaging |
RMB(tax included) | Beijing inventory | Shanghai inventory | Japanese inventory | Refer to delivery date | Query NO. | Purchase quantity |
|
2-8605-11 | E4 Wi-Fi | 80×60 | 0.15 | －20～＋250℃ | 10.3mrad | USB Micro | 1 | 17,200.00 14,620.00 | 0 | 0 | 6 |
|
**22 | - |
|
|
2-8605-22 | E5-XT | 160×120 | 0.1 | -20～+400℃ | 5.2mrad | USBMicro | 1 | 24,900.00 | 0 | 0 | 4 |
|
**21 | - |
|
|
2-8605-23 | E6-XT | 240×180 | 0.06 | -20～+550℃ | 3.4mrad | USBMicro | 1 | 36,900.00 | 0 | 0 | 2 |
|
**21 | - |
|
|
2-8605-24 | E8-XT | 320×240 | 0.05 | -20～+550℃ | 2.6mrad | USBMicro | 1 | 59,600.00 | 0 | 0 | 0 | 34 days or so | **21 | - |
※ It takes about 18 days to ship from Japan in case of storage in Japan
