Features:

※ Goods with maintenance inspection book, factory control, motor system maintenance, issued inspection book after the factory.
※ Paid IQ/OQ service.
① Error notification function (peace of mind and safety)② Wireless data logger function ③ 3-segment PID control ④ Bright large LCD screen
The opening and closing direction of the standard optional door (right open, left open), there is no observation window.
Standard with an independent digital device to prevent excessive temperature rise.
3-stage PID control mode can reduce the probability of temperature exceeding or below the required temperature range
Versatile timer function, including 4 timer functions, in addition to week, time specified timer, but also equipped with 16 step 8 mode program function.
LCD disy with good visibility and operability.
Connect non-standard equipment, can instantly identify errors.

Specifications:

Temperature control range: room temperature 20~300°C
Temperature variation (JIS):±3°C(at300°C)
Temperature control mode: 3-level PID control,SSR output
通信功能:规格:BluetoothSmart(Bluetooth4.2)/距离:Class2(约10m)
Recorder function :
▼ Recording mode: Full stop (stop recording with full memory)
▼ Recording cycle :2 seconds /10 seconds /30 seconds /60 seconds /10 minutes /60 minutes
▼ Disy cycle :2 seconds /10 seconds /30 seconds /60 seconds /300 seconds
External application :
▼ Functions: record start/stop, read/delete record data/transfer to PC/list disy, trend chart disy (can be enlarged, reduced)
▼ Record format :CSV format
▼ Corresponding OS:iOS10 and later
▼对应机种:iPhone5s·5c·6·6Plus·6s·6s·6sPlus·SE·7·7Plus·8·8Plus·X
Additional functions: timer (ON timer, OFF timer, SV start, ON/OFF timer)/ Maximum 10 steps ×8 modes of temperature gradient program/week/time specified timer
Safety device: digital set to prevent over-lift function, over-current circuit breaker, flout mechanism (heater OFF when the sensor is broken)
Temperature sensor :K thermocouple ×2 (temperature control, prevent over rise × 1 each)
Exterior/interior :SUS30/SUS60(part of SUS10J1)
Power supply :AC60V50/60Hz line length 10m(3P plug)
Accessories: shelf ×2 pieces · Time plug shelf guide ×2 sets
Attachment file: Check check file
※ Products with inspection certificates refer to the AZONE original service that controls the delivery, checks the motor system, and issues inspection certificates.
Products that correspond to the verification service (IQ/OQ). Please do ask.
* Verification service refers to the service of qualification verification (IQ) and operation performance qualification verification (OQ) during installation at the customer's site, and submission of inspection documents
※ Do not put combustible substances into the storage.

【 Specification sheet 】


Number

Model

Inside dimensions (mm)

The door

Maximum temperature arrival time

Temperature distribution (JTMK05)

Temperature gradient (JIS)

Sales Packaging

RMB(tax included)

Beijing inventory

Shanghai inventory

Japanese inventory

Refer to delivery date

Query NO.

Purchase quantity

1-9001-51-22

SONW-300SB

300×327×300

Left

About 35 minutes

±4℃(at300℃)

11℃(at300℃)

1 set

15,900.00 13,515.00

0

0

0

29天Left右

**12

-

1-9001-52-22

SONW-450SB

450×447×450

Left

About 40 minutes

±8℃(at300℃)

25℃(at300℃)

1 set

17,800.00 15,130.00

0

0

0

29天Left右

**12

-

1-9001-53-22

SONW-600SB

600×497×500

Left

About 80 minutes

±6℃(at300℃)

22℃(at300℃)

1 set

20,800.00 17,680.00

0

0

0

29天Left右

**12

-

1-9001-54-22

SONW-300SB-R

300×327×300

Right

About 35 minutes

±4℃(at300℃)

11℃(at300℃)

1 set

15,900.00 13,515.00

0

0

0

29天Left右

**12

-

1-9001-55-22

SONW-450SB-R

450×447×450

Right

About 40 minutes

±8℃(at300℃)

25℃(at300℃)

1 set

17,800.00 15,130.00

0

0

0

29天Left右

**12

-

1-9001-56-22

SONW-600SB-R

600×497×500

Right

About 80 minutes

±6℃(at300℃)

22℃(at300℃)

1 set

20,800.00 17,680.00

0

0

0

29天Left右

**12

-

※日本在库的情况下,从日本寄送大概需要18天Left右

Freight charge is extra
