Test parameters

L-Q, C-D, R-Q, |Z|-Q

Basic accuracy

0.25%

Equivalent circuit

Series, parallel

Range mode

Automatic, keep

Trigger mode

Inside

Test speed (1kHz) (times/second)

Fast :12, medium speed :5.1, slow speed :2.5

Calibration function

Open/short circuit, sweep frequency clean

Test end configuration

5 End

Test signal

Test signalFrequency

100Hz,120Hz,1kHz,10kHz,±0.01%

Output impedance

100 Ω

Test signal电平

0.3Vrms, 1Vrms

Measuring disy range

|Z|, R

0.1 mΩ — 99.99 MΩ

C

0.01pF — 99999μF

L

0.01μH — 99999H

D

0.0001 — 9.9999

Q

0.0001 — 9999.9

Show

Show方式

直读,带背光大字符LCDShow

Show器

Primary and secondary parameters: 5 - bits

General technical index

工作温度、 湿度

0 ℃ -40 ℃ ,≤75%RH

Power requirements

电压

198V-242V

Frequency

47.5Hz-63Hz

Power consumption

≤20VA

Volume

310(W)×108(H)×375(D)

The weight of

3.7kg
