Function

Need
Test conductor

The range of

Resolution

精度[1]

FieldSense
True RMS of AC voltage

None

600 V

1 V

±（3% + 3 次计数）45 Hz - 66 Hz[2][3]

FieldSense
True effective value of AC current

None

200.0 A

0.1 A

±(3% + 3 ) 45 Hz - 66 Hz

True RMS of AC voltage

It is

600 V

1 V

±(1.5% + 2 ) 45 Hz - 66 Hz

Dc voltage

It is

600 V

1 V

±(1% + 2)

Resistance

It is

2000 Ω

1 Ω

Safety level

600 V CAT III

精度[1] ：±（[读数的 %] + [低有效位数数字]）.精度在Calibrate后一年内适用,工作Temperature为 18 °C 至 28 °C（64 °F 至 82 °F）,相对Humidity至 90 %.AC 测量：交流耦合,RMS 响应.
精度[2] ：增加 3 %,None需外部接地连接.外引接地要求使用者配戴绝缘手套、站在绝缘梯上或以其他方式与地面绝缘.
精度[3] ：FieldSense 从 16 V 到满The range of均可.

Calibrate

1 年Calibrate周期

Size

61.1 x 259.3 x 43.8 mm

Jaw opening

17.8 mm

The weight of

0.35 kg (0.78 lb)

Temperature
Work:
Store:

-10°c - 50°c(14°f - 122°f
-30°c - 60°c(-22°f - 140°f)

Humidity
Work:
Store:

2,000 meters (6,562 feet)
10,000 meters (32,808 feet)

相对Humidity

0% - 90%，5°C - 30°C(41°F - 86°F)
0% - 75%，30°C - 40°C(86°F - 104°F
0% - 45%，40°C - 50°C(104°F - 122°F)

Battery type and service life

Two AA alkaline batteries (IEC LR6); 360 hours of standard endurance; 200 hours battery life (FieldSense)

Temperature系数

0.1x (precision specified) / °C (< 18°C or > 28 °C)
（<64.4 °F 或 > 82.4 °F）

Safety level

IEC/EN 61010-1: Pollution Level 2

Electromagnetic environment

IEC/EN 61326-1: Portable
