The monitor

240x64 点阵LCDThe monitor,6位读数分辨率

Test frequency

50Hz-200kHz,1.2 More than ten thousand frequency points

Test level range

10mVrms-2. 0Vrms,10mV Step by step

Basic accuracy

0.05%

Disy range

|Z|,R,X

0.00001Ω-99.9999MΩ

G,B

0.00001μS-999.999S

C

0.00001pF-999.999mF

L

0.00001μH-9.99999kH

D

0.00001-9.99999

Q

0.00001-99999.9

θ(DEG)

-179.999°-179.999°

θ(RAD)

-3.14159-3.14159

△ %

-999.999%-999.999%

Measure the speed of

Fast: 30 times/s, medium speed: 10 times/s, slow speed: 1.5 times/s

Equivalent circuit

Series, parallel

Range mode

Automatic, keep

Trigger mode

Internal, manual, external, Bus

The average number of times

1-255

Zero clearing function

Open circuit, short circuit, load correction

The measuring end

5 End

Disy mode

Direct reading, ΔABS, Δpercent, V/I(voltage/current monitoring), stop number and stop count

List scan

4 点频率, 电平, 直流偏置List scan测试

Comparator function

TH2816A

十档（九档合格,一档不格）另有一个附属档

Memory

12 Group internal instrument Settings for storage/call

Interface

TH2816A

RS-232C,HANDLER ,GPIB(optional)
