Basic accuracy

0.1%

Test frequency

50,60,100,120,1k,10k,20k,40k,50k,100k A total of 10 points

Test parameters

LCR

L 、C、R、|Z|、D、Q、X、θd、θr、Vm、Im、△%

Single group transformer

M ,N,1/N,L1/L2,DCR1/DCR2,C (primary and secondary),P (phase),Lk1/Lk2 (leakage)

Balance

Balance：L、R、Z、DCR

V/I Monitor

There is

Test level

AC

0.01Vrms、0.02Vrms、0.05Vrms、0.1Vrms、0.25Vrms、0.5Vrms、1Vrms

DC Test level

±1V

Internal resistance of signal source

10 Ω、100Ω可选

Test end configuration

5 End

Test speed (ms/ time)

Fast :19ms, medium speed :83ms, slow speed :333ms

Zero clearing function

Open circuit, short circuit, load

List scan

10 Click Any Settings

Equivalent mode

Series, parallel

Range mode

Automatic, keep

Trigger mode

Internal, manual, external, Bus

The average number of times

1-255

Mathematical operation

Direct reading,△ABS,△percent

Delay time

触发Delay time,步进Delay time: 0—60.000s,1ms步进

Comparator

10 File sorting,BIN1 ~ BIN9,NG,AUX PASS,FALL front panel LED disy, qualified ring

Storage

内部非易失性Storage

100 Group LCRZ instrument setup document

外部USBStorage器

Instrument setup file,CSV data file
