Product specifications: Fluke BT5300 series high precision battery tester
| Parameter |
|
| Measuring items | Ac resistance, DC voltage, side voltage detection |
| Measuring method | 交流4 Terminal method ( 1KHz ） |
| Rated input | DC± 11V |
| Input impedance | 10MΩ , High resistance (--) >10GΩ ） |
| Sampling speed | Super fast/ Fast / 中速 / Slow speed Fourth gear |
| Supported loop resistance | 3mΩThe range of ≤ 10 Ω |
| 其他The range of≤ 20 Ω | |
| Trigger | 内部/ External |
| Delay | ON/OFFDelay时间： 0~9.999 Second |
| On average | ON/OFF,On averageTimes数 2 ~ 16 Times |
| Test value store | At most512 Group |
| Channel extension | Internal: Insert two multi-channel scanning modules
SW9010
,
At most
64
A channel (
Only BT5311 and BT5321 support
）
External：连接开关主机 SW1080,At most256个通道 |
| External接口 | RS-232C , LAN |
| Other functions | Contact detection |
| Sampling time |
|
| Sampling speed ： Ac internal resistance and DC voltage are collected simultaneously | Sampling time(50Hz/60Hz) |
| Super fast | 10ms / 8.3 ms |
| Fast | 20ms / 16.7 ms |
| 中速 | 100ms / 83.3 ms |
| Slow speed | 200ms / 166.7 ms |
| Measuring range and accuracy |
|
|
|
|
|
| Ac resistance measurement |
|
|
|
|
|
| The range of | 3mΩ | 30mΩ | 300mΩ | 3Ω | 10Ω |
| Maximum disy value | 5.0000 mΩ | 50.000 mΩ | 500.00 mΩ | 5.0000Ω | 15.000Ω |
| Resolution | 0.1µΩ | 1 µΩ | 10 µΩ | 100 µΩ | 1mΩ |
| 测试电流1 | 100/200/300 mA² | 100 mA | 10 mA | 1 mA | 1 mA |
| Test current frequency | 1 kHz±1 Hz | ||||
| Precision ³ | 0.2%*读数 + 6 A word | ||||
| Temperature coefficient | (0.05%*读数 + 0.005%* 满The range of )/ ° C | ||||
| Response time (pure resistance) (< 18°C or > 28°C) | <20ms | ||||
| 1. Test current error ±10% |
|
|
|
|
|
| 2.
针对3mΩ range,Slow speed采样率下,不同测试电流的精度为
100mA 0.5%*读数+20A word 200mA 0.3%*读数+12A word 300mA 0.2percent* Reading+6A word |
|
|
|
|
|
| 3.在不同Sampling speed下,额外增加误差
3mΩ range Super fast：± 30字, Fast ± 10字, 中速 ± 5字 30mΩ ~ 10ΩThe range of Super fast：± 3字, Fast ± 2字, 中速 ± 2字 |
|
|
|
|
|
| Dc voltage measurement |
|
|
|
|
BT5310/BT5311 | BT5320/BT5321 |
| Number of digits | 6.5位 | 7.5位 |
| The range of | 10V | |
| Maximum disy value | ±11.00000 V | ±11.000000 V |
| Resolution | 10 µV | 1 µV |
| 精度1 | 25ppm*读数 + 50 µV | 16ppm*读数 + 15 µV |
| Response time (typical value) | <20ms | <20ms |
| Temperature coefficient（＜18°C 或 ＞28°C ） | (5ppm*读数 + 1ppm* 满The range of ) / ° C | (1ppm*读数 + 1ppm* 满The range of )/ ° C |
| 1. 在不同Sampling speed下,需要额外增加误差
BT5310/BT5311 Super fast：±50 μV;Fast：±30 μV;中速：±10 μV BT5320/BT5321 Super fast：±50 μV;Fast：±20 μV;中速：±5 μV |
|
|
| Model comparison |
|
|
|
|
| Characteristic | BT5310 | BT5311 | BT5320 | BT5321 |
| 直流电压Resolution | 6.5位 | 7.5位 | ||
| 仪器内部It isNo能插入多通道扫描模块SW9010 | No | Yes, At most插入 2 A module | No | Yes, At most插入 2 A module |
| 仪器ExternalIt isNo能连接开关主机SW1080 | It is | It is | It is | It is |
| Common index |
|
| 尺寸( Long * The width * Deep (--) | BT5300电池测试仪： 216mm * 133mm * 383mm |
| SW1080开关主机： 430mm * 128mm * 260mm | |
| SW9010扫描模块： 202 mm * 26mm * 222mm | |
| The weight of | BT5300电池测试仪： 7.3kg ( Does not contain SW9010) |
| SW1080开关主机： 9kg ( Does not contain SW9010) | |
| SW9010扫描模块： 500 g | |
| Show | 4.3英寸 , TFT LCD ,Resolution 480x272 |
| Operating temperature | 0 °C to +40 °C |
| Storage temperature | -10 °C to +50 °C |
| Operating humidity | 无凝结（<10°C ） |
| ≤90% RH (at 10°C to 30°C) | |
| ≤75% RH (at 30°C to 40°C) | |
| ≤45% RH (at 40°C to 50°C) | |
| Altitude | 3000米 |
| Storage altitude | 12000米 |
| Rated power supply voltage | AC100V~240V（自动切换） |
| Rated power supply frequency | 50/60Hz |
| Rated power | 60 VA |
| Safety rules | IEC 61010-1: Pollution Degree 2 |
| Electromagnetic compatibility | IEC 61326-1: Industrial |
| Warranty | BT5300 Battery tester:3年
SW1080 Switch host:3年 SW9010 Scan module:1年 注：继电器,保险丝和连接器不属于Warranty对象 |
