Product specifications: Fluke 810 vibrometer
| Diagnostic technical index | ||
| Standard failure | Unbalanced, loose, neutralized bearing failure | |
| Analysis | Motors, fans, blowers, belt and chain drivers, transmissions, couplings, centrifugal pumps, piston pumps, slide pumps, propeller pumps, screw pumps, rotary screw/gear/CAM pumps, piston compressors, centrifugal compressors, screw compressors, tightly connected machines, mandrels | |
| Machine speed range | 200rpm - 12000rpm | |
| Diagnostic details | in text diagnosis, fault severity rating (mild, moderate, severe, extremely severe), repair details, peak citations, spectrum | |
| Electrical technical specifications | ||
| Range transformation | Automatic | |
| A/D converter | 4 channels,24 bits | |
| Available bandwidth | 2hz - 20khz | |
| Sampling | 51.2 Hz | |
| Digital signal processing function | Automatic配置的防失真滤波器、高通滤波器、抽样、重叠、加窗、FFT 和平均 | |
| Sampling率 | 2.5 kHz- 50khz | |
| Dynamic range | 128 dB | |
| Signal-to-noise ratio | 100 dB | |
| FFT resolution | 800 line | |
| Spectrum window | Hanning window (Hanning window) | |
| A unit of frequency | Hz、orders、cpm | |
| Unit of amplitude | in/sec、mm/sec、VdB（美国）、VdB*（欧洲） | |
| Nonvolatile memory | SD micro memory card,2 GB memory user expansion storage slot (additional storage space) | |
| General technical index | ||
| Dimensions (height x depth x width) | 18.56 x 7.00 x 26.72 cm (7.30 x 2.76 x 10.52 in) | |
| Weight (including battery) | 1.9 kg (4.2 lb) | |
| The disy screen | ¼ VGA,320 x 240 color (5.7 inch diagonal) LED backlit TFT LCD | |
| I/O connection | Three-axis sensor connection | 4-pin M12 Connector |
| Uniaxial sensor connection | BNC connector | |
| Tachometer connection | Mini DIN 6-pin Connector | |
| PC connection | Mini 'B' USB (2.0) connector | |
| Battery | Battery类型 | Lithium ion, 14.8V, 2.55Ah |
| Battery充电时间 | Three hours | |
| Battery放电时间 | 8 hours (under normal conditions) | |
| Ac adapter | Input voltage | 100vac - 240vac |
| Input frequency | 50/60 Hz | |
| Operating system | WinCE 6.0 Core | |
| Language support | English, French, German, Italian, Japanese, Portuguese, Simplified Chinese, Spanish | |
| Warranty period | Three years | |
| Environmental indicators | ||
| Operating temperature | 0°c - 50°c(32°f - 122°f | |
| Storage temperature | -20°c - 60°c(-4°f - 140°f) | |
| Operating humidity | 10percent to 95percent relative humidity (no condensation) | |
| Institutional certification | CHINA RoHS、CSA、CE、C TICK、WEEE | |
| Electromagnetic compatibility | En 61326-1:2006, En 61010:1:2001第2版 | |
| Sensor technical specifications | ||
| Sensor type | Accelerometer | |
| Sensitivity | 100 mV/g（±5%,25 °C） | |
| Acceleration range | 80 g peak | |
| Amplitude nonlinearity | 1% | |
| Frequency response | Z | 2 . 7000hz±3dB—— |
| X,Y | 2 . 5 000hz±3dB—— | |
| Power Supply requirements (IEPE) | 18 VDC - 30 VDC,2 mA- 10 mA | |
| Offset the output voltage | 12 VDC | |
| Ground | 外壳Ground | |
| Sensor element design | PZT ceramic/shear type | |
| Shell material | 316L Stainless Steel | |
| Fastener | 10-32 Capacitive Hexagon head screws with 2-pole rare earth magnet (48 lb pull strength) | |
| Output connector | Four needles,M12 | |
| Matching connector | M12 - F4D | |
| Nonvolatile memory | TEDS 1451.4 compatible with | |
| Vibration limit | 500 g peak | |
| Shock limit | 5000 g peak | |
| 电磁Sensitivity,等效 g | 100 MCG/gauss | |
| Sealing performance | Airtight seal | |
| Temperature range | -50°C - 120°C(-58°F - 248°F)±7% | |
| Warranty period | 1 year | |
| Technical index of tachometer | ||
| Dimension (D x W) | 2.86 x 12.19 cm (1.125 x 4.80 in) | |
| The weight of | 96 g (3.4oz) including cable | |
| Power supply | Powered by 810 vibrometer | |
| Detect | Class 2 laser diode | |
| The range of | 6.0 | |
| Precision | 6.0 - 5999.9 rpm | ± 0.01percent and ± 1 digit |
| 5999.9 rpm | ± 0.05percent and ± 1 digit | |
| Resolution | 0.1 rpm | |
| Effective range | 1厘米- 100厘米(0.4英寸- 39.27英寸 | |
| Response time | 1 s (> 60 rpm) | |
| Control | Measure the on/off transparent button | |
| Interface | 6 .迷你DIN | |
| Cable length | 50 cm (19.586 in) | |
| Warranty period | 1 year | |
| Tachometer accessories | Reflective tape | 1.5 x 52.5 cm (0.59 x 20.67 in) |
| Viewer PC software | ||
| Minimum hardware requirements | 1gb内存—— | |
| Operating system要求 | Windows XP、Vista | |
