Technical parameters
Model number
TH2681
Resistance test range
100kΩ-5TΩ
Test accuracy
10% The reading is 0.5 grid
Test voltage
10V/25V/50V/100V/250V/500V
Voltage accuracy
±5%
Measure the current range
≤100μA
Control mode
Analog circuit
Trigger mode
None
Range mode
Manual
Test the speed
Resistive components: < 0.5 s Capacitive components: 0.5-1.0 s
Sorting
Pass, reject and reject ring (can be switched)
Interface
Attachment
| Standard configuration | |||||
| Part name | Model number |
|
|
|
|
| Test line at both ends | TH26004B |
|
|
|
|
| Optional | |||||
| Part name | Model number |
|
|
|
|
