快速选型
| 型号 | 电流 | 电压 | 功率 | 功能 | 标配接口 |
| PSR 36-7 | 7A | 36V | 108W | 开关 | USB/GPIB |
| PSR 60-6 | 6A | 60V | 150W | 开关 | USB/GPIB |
| 详细规格 | ||
| PSR 36-7 | PSR 60-6 | |
| 额定输出 | ||
| 电压 | 0 ~ 36V | 0 ~ 60V |
| 电流 | 0 ~ 7A | 0 ~ 6A |
| 功率 | 108W | 150W |
| 定电压 (CV) | ||
| 负载调节率 | 0.01% + 2mV | 0.01% + 2mV |
| 电源调节率 | 0.01% + 2mV | 0.01% + 2mV |
| 定电流(CC) | ||
| 负载调节率 | 0.01%+ 250uA | 0.01%+ 250uA |
| 电源调节率 | 0.01%+ 250uA | 0.01%+ 250uA |
| 涟波& 杂讯 | ||
| 定电压(峰值) | 2mVp-p | 3mVp-p |
| 定电压(有效值) | 0.35mVrms | 0.5mVrms |
| 定电流(有效值) | 2mArms | 2mArms |
| 程控度 | ||
| 电压 | 0.05%+10mV | 0.05%+10mV |
| 电流 | 0.2%+10mA | 0.2%+10mA |
| 回读度 | ||
| 电压 | 0.05%+5mV | 0.05%+5mV |
| 电流 | 0.15%+5mA | 0.15%+5mA |
| 反应时间 | ||
| 上升时间(满载) | <40ms | <100ms |
| 上升时间(空载) | <20ms | <35ms |
| 下降时间(满载) | <40ms | <50ms |
| 下降时间(空载) | <400ms | <500ms |
| 瞬态回复时间(负载变化从 50 到) | <30uSec | <50uSec |
| GPIB命令询问 | <20ms | <20ms |
| 程控与量测解析度 (By PC Remote Control Mode) | ||
| 电压 | 1mV | 1mV |
| 电流 | 0.1mA | 0.21mA |
| 程控与量测解析度 (By Front Panel) | ||
| 电压 | 1mV | 10mV |
| 电流 | 0.1mA | 1mA |
| 程控与量测解析度 (By Analog Programming Interface) | ||
| 电压 | 1mV | 1mV |
| 电流 | 0.21mA | 1mA |
| 串并联连接 | ||
| 并联 | 多7台，包含Master | NA |
| 串联 | 多7台，包含Master | NA |
| 保护功能 | ||
| 过电压保护 | YES | YES |
| 过电流保謢 | YES | YES |
| 过温度保护 | YES | YES |
| 环境特性 | ||
| 操作温度 | 0℃ to 40℃ | |
| 储存温度 | -40℃ to 70℃ | |
| 操作湿度 | Maximum relative humidity 80% for temperature up to 35℃ | |
| 温度系数 | ||
| 电压 | 0.01%+3mV | 0.01%+10mV |
| 电流 | 0.02%+3mA | 0.02%+3mA |
| 其它 | ||
| 类比控制 | Yes | |
| 界面 | USB & GPIB | |
| 输入电源 | 100V - 120V (115V Range)/220V - 240V (230V Range), 47~63Hz | |
| 尺寸&重量 | 220(W) x 88(H) x 303.9(D)mm; Approx. 2.5kg | |
